HDPE Coiled Conduit
Raw Materials: PE100
Standards: ISO 4427 / EN 12201
Diameter :DN20mm-110mm
Pressure Rating : SDR33 - SDR11
Certificates : ISO,CE
Length in coil : 100m per coil (could be customized )
Color : Black pipe / orange( color could be customized )
Description
Specification
Certificate
Case
Product Description
High-density polyethylene (HDPE) conduit is the preferred material to house and protect electrical power and telecommunications cables within. It offers unmatched corrosion and chemical resistance, is flexible, durable and available in long coil lengths to reduce joints and installation time.
Product Specification
Nominal Pressure PE 100 |
SDR 11 | SDR 13.6 | SDR 17 | SDR 21 | SDR 26 | SDR 33 |
PN 16 | PN 12.5 | PN 10 | PN 8 | PN 6 | PN 5 | |
Nominal Size DN (mm) | Min Wall (mm) | Min Wall (mm) | Min Wall (mm) | Min Wall (mm) | Min Wall (mm) | Min Wall (mm) |
20 | 2.0 | – | – | – | – | – |
25 | 2.3 | 2.0 | – | – | – | – |
32 | 3.0 | 2.4 | 2.0 | – | – | – |
40 | 3.7 | 3.0 | 2.4 | 2.0 | – | – |
50 | 4.6 | 3.7 | 3.0 | 2.4 | 2.0 | – |
63 | 5.8 | 4.7 | 3.8 | 3.0 | 2.5 | – |
75 | 6.8 | 5.6 | 4.5 | 3.6 | 2.9 | – |
90 | 8.2 | 6.7 | 5.4 | 4.3 | 3.5 | – |
110 | 10.0 | 8.1 | 6.6 | 5.3 | 4.2 | – |
Product Certificates
Cases
Project: GBC SPS-C3 HDPE Electrical Couduit Project
Product: HDPE Conduit Pipe
DN40-63mm SDR11 PN16
Location: Singapore
